(Redirected from Digifant Engine Management system)
A Digifant II DF-1 Engine Control Unit used in '91 Volkswagen Golf Cabriolet with 2E engine

The Digifant engine management system is an electronicengine control unit (ECU), which monitors and controls the fuel injection and ignition systems in petrol engines, designed by Volkswagen Group, in cooperation with Robert Bosch GmbH.

Digifant is the outgrowth of the Digijet fuel injection system first used on water-cooled VolkswagenA2 platform-based models.

History[edit]

Digifant was introduced in 1986 on the 2.1 litreVolkswagen Type 2 (T3) (Vanagon in the US) engine. This system combined digital fuel control as used in the earlier Digi-Jet systems with a new digital ignition system. The combination of fuel injection control and ignition control is the reason for the name 'Digifant II' on the first version produced. Digifant as used in Volkswagen Golf and Volkswagen Jetta models simplified several functions, and added knock sensor control to the ignition system. Other versions of Digifant appeared on the Volkswagen Fox, Corrado, Volkswagen Transporter (T4) (known as the Eurovan in North America), as well as 1993 and later production versions of the rear-engined Volkswagen Beetle, sold only in Mexico. Lower-power versions (without a knock sensor), supercharged, and 16-valve variants were produced. Nearly exclusive to the European market, Volkswagen AG subsidiaryAudi AG also used the Digifant system, namely in its 2.0 E variants of the Audi 80 and Audi 100.

Digifant is an engine management system designed originally to take advantage of the first generation of newly developed digital signal processing circuits. Production changes and updates were made to keep the system current with the changing California and federal emissions requirements. Updates were also made to allow integration of other vehicle systems into the scope of engine operation.

Vw Digifant Manual Transmission

Changes in circuit technology, design and processing speed along with evolving emissions standards, resulted in the development of new engine management systems. These new system incorporated adaptive learning fuzzy logic, enhanced and expanded diagnostics, and the ability to meet total vehicle emissions standards.

Features[edit]

Fuel injection control is digitally electronic. It is based on the measurement engine load (this signal is provided by the Air Flow Sensor), and on engine speed (signal provided by the Hall sender in the distributor). These primary signals are compared to a 'map', or table of values, stored in the Engine Control Module (ECM) memory.

The amount of fuel delivered is controlled by the duration of actuation of the fuel injector(s). This value is taken from a programme in the ECM that has 16 points for load and 16 points for speed. These 256 primary values are then modified by coolanttemperature, intake air temperature, oxygen content of the exhaust, car battery voltage and throttle position - to provide 65,000 possible injector duration points.

Digifant is unlike the earlier CIS and CIS-E fuel injection systems that it replaced, in that fuel injectors are mounted on a common fuel rail. CIS fuel injection systems used mechanical fuel injectors. The fuel injectors are wired in parallel, and are supplied with Constant System Voltage. The ECM switches the earth/ground on and off to control duration. All injectors operate at the same time (simultaneously, rather than sequentially) each crankshaft revolution; two complete revolutions being needed for each cylinder to receive the correct amount of fuel for each combustion cycle.

Ignition system control is also digital electronic. The sensors that supply the engine load and engine speed signals for injector duration provide information about the basic ignition timing point. The signal sent to the Hall control unit is derived from a programme in the ECM that is similar to the injector duration programme.

Engine knock control is used to allow the ignition timing to continually approach the point of detonation. This is the point where the engine will produce the most motive power, as well as the highest efficiency.

Additional functions of the ECM include operation of the fuel pump by closing the Ground for the fuel pump relay, and control of idle speed by a throttle plate bypass valve. The Idle Air Control Valve (IACV) (previously known as an Idle Air Stabiliser Valve - IASV), receives a changing milliamp signal that varies the strength of an electromagnet pulling open the bypass valve.

Idle speed stabilisation is enhanced by a process known as Idle Speed Control (ISC). This function (previously known as Digital Idle Stabilization), allows the ECM to modify ignition timing at idle to further improve idle quality.

Digifant II inputs/outputs[edit]

The 25 pin electronic control unit used in the Golf and Jetta receives inputs from the following sources:

  • Hall sender unit (provides engine speed signal)
  • Air Flow Sensor (provides engine load information)
  • Coolant temperature sensor
  • Intake Air Temperature sensor
  • Knock sensor
Digifant

Additional signals used as inputs are: Hp proliant ml150 g6 drivers linux ubuntu.

  • Air conditioner (compressor on)
  • Car battery voltage
  • Starter motor signal
Digifant system inputs/outputs

The Anti-lock Braking System (ABS), three-speed automatic transmission, and vehicle speed sensor are not linked to this system.

Outputs controlling engine operation include signals to the following:

  • Fuel injectors
  • Idle Air Control Valve
  • Hall control unit
  • Fuel pump relay
  • Oxygen sensor heater

Additional systems[edit]

The evaporative emission system is controlled by a vacuum-operated mechanical carbon canistercontrol valve. Fuel pressure is maintained by a vacuum operated mechanical fuel pressure regulator on the fuel injector rail assembly. Inputs and outputs are shown in the following illustration. Digifant II as used on Golf and Jetta vehicles provides the basis for this chart.

North America variants[edit]

In North America, Volkswagen released two other versions of the Digifant fuel injection system (in addition to standard Digifant II described above).

A limited number of 1987-1990 California Golf and Jetta models are equipped with Digifant II that features an on-board diagnostics system (OBD). These vehicles have 'blink code' capacity to store up to five Diagnostic Trouble Codes (DTCs). Diagnostic troubleshooting is done by pressing the Check Engine switch on the dashboard. This system can also have carbon monoxide (CO), ignition timing and idle speed adjusted to baseline values.

In 1991, California Golf, Jetta, Fox, Cabriolet and Corrado vehicles were equipped with expanded OBD capabilities. This version was renamed 'Digifant I'. These later Digifant versions have 38-pin ECMs with Rapid Data Transfer and permanent DTC memory. All Eurovans with Digifant also have rapid data transfer and permanent DTC memory. These systems use a throttle plate potentiometer to track throttle plate position in place of the idle and full throttle switches used on earlier systems.

Another characteristic of Digifant II equipped vehicles in California is a switch mount on the dashboard which has a 'Check Engine' symbol. Digifant I models in California feature a Check Engine light, with the display of codes done by a special Volkswagen tool under the shift boot, or by a jumper and an LED by the home mechanic.

Digifant Reliability[edit]

Vehicles using engines equipped with Digifant fuel injection typically operated both efficiently and smoothly when new but suffered from a number of issues as the car aged, even by a few months. Digifant sensors & other components, especially the ECU itself, were remarkably sensitive to poor electrical grounding. Without a reliable ground signal to reference, the system was vulnerable to errors and malfunction. In the 1980s and 1990s many Volkswagen / Audi designs did not incorporate sufficient engine compartment grounding, and when the car's engine compartment became soiled with dirt, oil & road salts from several months / years of use, the fuel injection system would fail in often inexplicable ways. Backfiring, stalls & other poor running were all too common. Later versions were improved by providing multiple grounding paths, but the early Digifant systems suffered poor service reputations.

Most of driveability issues can be traced back to a few issues:

  • Bad ECM earth/ground
  • Bad o2/lambda sensor earth/ground
  • Faulty Engine Coolant Temperature sensor (ECT)

Vw Digifant Manual Download

The engine coolant temperature sensor is located in the coolant flange,(under the distributor on the Polo Fox Coupe) on the front of the cylinder head (on transverse-engine vehicles). The bad earth/ground can be traced to an essential ground strap on the front upper transmission bolt. Without this, the ECU tends to earth/ground elsewhere, causing a specific trace to burn out on the circuit board and killing the ECU. This causes the injectors to stay open constantly, flooding the engine.

1990 Jetta GL with Digifant engine management

Common issues that indicate a failed engine coolant temperature sensor are:

  • Vehicle idles poorly
  • Engine sputters, might stall
  • Higher than normal fuel consumption

The part number for this sensor is '025 906 041 A' (always check with your Volkswagen dealer for the most updated part number). The resistance of this unit is approximately 3.2 Kohm at 10 degrees C. If it measures open circuit this will explain erratic idle and throttle speeds especially when the engine is cold.

When replacing this sensor, it is important to also replace the clip that holds it in position ('032 121 142') and the O-ring ('N 903 168 02').

Once the new sensor has been installed, start the engine and disconnect the blue coolant temperature sensor. Rev the engine through 3,000 rpm three times, each time allowing the throttle to close completely. This clears the Digifant ECM fault memory.
